SQUARE TUBING ELBOWS
Model Square Degree INSIDE Wall Center Line Center To
Number Tubeing Of Elbow Radius (r) Thick. Radius(R) Center (C-C) .
6300-35.................... 1".........................35°.................................................................. 2 1/2"............... .083"................. 3" (NO SEAM)............
6302-45.................... 1".........................45°.................................................................. 2 1/2"............... 083".................. 3" (NO SEAM)............
6304-55.................... 1".........................55°.................................................................. 2 1/2"............... .083"................. 3" (NO SEAM)............
6306-90.................... 1".........................90°.................................................................. 2 1/2"............... .083"................. 3" (NO SEAM)............
6308-290.................. 1".........................90° W/TWO 2" TANGENTS......................... 2 1/2"............... .083"................. 3" (NO SEAM)............
6313-180.................. 1".........................180° W/TWO 2" TANGENTS....................... 2 1/2"............... .083"................. 3" (NO SEAM)............6"
6332-45.................... 1 1/4"...................45°.................................................................. 3 1/8"............... .083"................. 3 3/4" (NO SEAM)......
6334-55.................... 1 1/4"...................55°.................................................................. 3 1/8"............... .083"................. 3 3/4" (NO SEAM)......
6336-90.................... 1 1/4"...................90°.................................................................. 3 1/8"............... .083"................. 3 3/4" (NO SEAM)......
6343-180.................. 1 1/4"...................180° W/TWO 2" TANGENTS....................... 3 1/8"............... .083"................. 3 3/4" (NO SEAM)......7 1/2"
6360-35.................... 1 1/2"...................35°.................................................................. 3 3/4"............... .083"................. 4 1/2" (NO SEAM)......
6362-45.................... 1 1/2"...................45°.................................................................. 3 3/4"............... .083"................. 4 1/2" (NO SEAM)......
6366-90.................... 1 1/2"...................90°.................................................................. 3 3/4"............... .083"................. 4 1/2" (NO SEAM)......
6368-290.................. 1 1/2"...................90° W/TWO 2" TANGENTS......................... 3 3/4"............... .083"................. 4 1/2" (NO SEAM)......
6380-35.................... 2".........................35°.................................................................. 7"...................... .120"................. 8" (NO SEAM)............
6382-45.................... 2".........................45°.................................................................. 7"...................... .120"................. 8" (NO SEAM)............
6384-55.................... 2".........................55°.................................................................. 7"...................... .120"................. 8" (NO SEAM)............
6386-90.................... 2".........................90°.................................................................. 7"...................... .120"................. 8" (NO SEAM)............
6388-290.................. 2".........................90° W/TWO 2" TANGENTS......................... 7"...................... .120"................. 8" (NO SEAM)............
6393-180.................. 2".........................180° W/TWO 2" TANGENTS....................... 7"...................... .120"................. 8" (NO SEAM)............16"
Elbow 35 degree
(Without a seam) Elbow 45 degree
(Without a seam)
Elbow 55 degree
(Without a seam)
Elbow 90 degree
(Without a seam)
Elbow 90 degree
with two 2" tangents
(Without a seam)
Elbow 180 degree
with two 2" tangents
(Without a seam)
NO MITRE-NO SHARP CORNERS
THIS COST-CUTTING CORNER SIMPLIFIES FIT-UPAND
SHORTENS FABRICATION.SIMPLY SQUARE CUT YOUR
TUBING
RADIUS
EQUALS
THE TUBING
SIZE
SQUARE TUBING
CORNERS FOR ROUND CORNER TUBING
NOT RECOMMENDED FOR SQUARE
CORNER EXTRUDED TUBING
SQUARE WALL . MODEL
TUBING THICK. NUMBER
1"......................... .075"....................W-9210-TC
1 1/4"................... .075"....................W-9215-TC
1 1/2"................... .075"....................W-9220-TC
2"......................... .075"....................W-9225-TC
4"......................... .104"....................W-9425-TC
