LOCINOX LOCK FOR SWING GATES
WIDE/NARROW ORNAMENTAL-STAINLESS STEEL
*Stainless steel internal components.
No ferrous materials
*Cast aluminum lockbox,lock body width 3 1/4”
*Two piece stainless steel latch bolt and deadbolt.
:LH/RH reversible form outside the lockbox
:Throw lenght: 1”
:Latch bolt/dead bolt external adjustment
*The standard & security keepers require a 1 1/4 latch gap
*Europrofile double cylinder w/3 keys,nickel
:Yale Y220 compatible
:Available keyed alike or keyed differently
:Key operated latch bolt (spring latch function)
*Four hole mounting; Fast & Easy
:Two mount bolts,recessed socket head bolts 8 mm
:Two “through gate frame”latchbolt & dead bolt holes
*Available in the following colors .BLACK & ALUMINUM
Narrow Ornamental lock for swing gates
(Check out handle description before ordering)
(Note:All The Lockboxes Are 1 3/16" Thick x 3 1/8”)
MODEL
NO. FRAME/THICKNESS COLOR
#LAPY10FBL.... 3/8''-3/4”....................... BLACK
#LAKY20FBL.... 1".................................. BLACK
#LAKY30FBL.... 1-1/4"............................ BLACK
#LAKY40FBL.... 1-1/2"............................ BLACK
#LAKY50FBL.... 2".................................. BLACK
Note: Note: Special Order Cylinders are avaible in Schlage & Kwikset Only
Wide Ornamental lock for swing gates
(Check out handle description before ordering)
(Note:All The Lockboxes Are 1 3/16" Thick x 3 9/16”)
MODEL
NO. FRAME/THICKNESS COLOR
#LAPQ10HBL... 3/8 "-3/4”...................... BLACK
#LAKQ30HBL... 1 1/4"............................ BLACK
#LAKQ40HBL... 1-1/2"-2"...................... BLACK
#LAKQ60HBL... 2 1/2. ............................. BLACK
Left/Right hand reversible
Throw & Key operation
Adjustable 3/8” continuous
Adjustable 3/4” continuous
Mounting & Center line spacing
stainless steel
LOCINOX LOCKS FOR SWING GATES
Wide Ornamental lock
for swing gates
Check out handle description
before ordering
NARROW Ornamental lock
for swing gates
Check out handle description
before ordering
Best fit for custom
ornamental iron
gates
MODEL #
IN COLOR BLACK
COMES
WITH THE BLACK
ORNAMENTAL
HANDLES & BLACK
BOX
MODEL
NO.
3019LA
ROUND ADAPTOR PLATE
FOR LA & LS LOCKS
MODEL
NO.
#CLH....... SILVER
#CLHBL.. BLACK
chain link holder
Note: Note: Special Order Cylinders are avaible in
Schlage,Kwikset,Medeco & Best sfic (small format interchangeable core)
Note: Recommended Keeps
#SHKLQFBL
#SHKLQFAL
#SAKLQFBL
#SAKLQFAL
(Description on the following pages)
