184
Orleans Ornamental Iron & Casting Dist.,Inc.
2860 Arts St., New Orleans, La. 70122
Tel: (504) 945-4466 Fax: (504) 947-4363 Toll: (800)824-3608
MODEL #SAMSON2
*Opening angle up to 150° depending on the situation
*Adjustable closing speed & closing pressure
*New: Continuously adjustable final snap for a perfect closing
*Specially developed for outdoor use: industrial quality
*Closing speed unaffected by temperature changes
*Fast and easy installation: Quick-fix *For left & right turning gates
*For gates up to 330 lbs (max 6-1/2 ft wide)
*Tested at 500,000 movements *Tested to -22° F
MODEL #
3200
(BLACK FINISH)
PERFECT
FOR
WALKGATES
(HYDRAULIC)
:Flush Mount Gate Closer
:Adjusting Screw Regulates Closing Speed
:Installs On Top,Middle Or Bottom Of Gate
:Mounts On Opening Side Of Gate And Pushes The Gate Closed
Specifications:
Max Gate Weight: 125 Lbs:
Max Gate Width: 54 In.
Max Opening Angle :90 Degrees
HAS FRONT
COVER PLATE
MODEL #
3240
(BLACK FINISH)
WALK GATE CLOSER
(HYDRAULIC)
BLACK FINISH
PULLS
GATE CLOSE
EASILY,GENTLYAND
SMOOTHLY
(HEAVY DUTY)
*Easy installation,compact and durable *over 100,000
operations tested * 90 degrees Hold open functions
*Two-speed closing *Suitable for indoor or outdoor installation
*Designed speciality for use on Metal Gates,can also be used
on wooden doors *Weight limit per closer up to 120 lbs
GATE SPRING
12”(BLACK)
MODEL
# 3514T
*Safety-tension adjustable to ensure
gate closes long after installation
CLOSERS & SPRINGS FOR DOORS OR GATES
*Long-life-tested to over 1 million cycles
*Safety-tension adjustable to ensure gate
closes long after installation
*Easy-to adjust-springs include stickers to
assist consumer in adjusting tension
GATE SPRING
14”(BLACK)
MODEL
# 410002
MODEL #
VGC-180
*Force,speed,and final snap are easily adjustable
after installation
*Closing speed unaffected by humidity and
temperature changes
*Specially developed for outdoor use:industrial quality
*Maximum opening angle:180 degree
(no “GATESTOP”needed)
*Ideal in combination with 180 degree hinges
*Powder coated aluminum casing
*For left and right turning gates
*For gates up to 260 lbs (max 4 ft. wide)
*Tested at 500,000 movements
*Tested to -22 degrees F
LOCINOX
VERTICLOSE
GATE
CLOSER
Note:Can Be Installed To Push
The Gate Closed Or Mounted
On The Secure Side Of The
Gate To Pull The Gate Closed
MODEL #
M180BL (BLACK)
MODEL #
M180SL (SILVER)
Maxium Weight 330 Lbs/Maxium Width 48”
*Mammoth Self Closing Hinge Opens (180°) Includes
Bottom Dino Hinge
*Design For Exterior Use Regardless Of The Outside
Temperature
*ADA Compliant 3.5 Lbs.Opening Pressure
*Adjustable Closing Speed & Closing Pressure
*Adjustable Sweep For Perfect Closing (Final Snap)
* Fast and Easy Installation With Quick Fix Fasteners
As Shown Here
*Ideal In Combination With Magnetic And Mechanical
Locks
*For Gates That Opens Left Or Right
*Minium post size 2” & Minium Gate Size 1 1/2”
*Double Stainless Steel Bearing
*Pushers The Gate Close
QUICK-FIX
1 1/2”LONG
DRILL 9/16-5/8
HAMMERED
&
SCREW
INTO
FRAME
MODEL
NO
#
QF2
(2 PER-SET)
OPEN
CLOSED
POST BRACKET
NOW THE SAMSON2
CAN BE INSTALLED ON
CHAIN LINK GATES AS
EASILYAS ON
ORNAMENTAL GATES
G
alvanized
S
teel
B
rackets
A
nd
U-B
olts
MODEL# (
for
samson
2
chain
link gates
post
)
SB4020
-F
its
4”OD P
ost and
1 7/8”OD.G
ate
F
rame
SB4015
-F
its
4”OD P
ost and
1 5/8”OD.G
ate
F
rame
SB3020-
F
its
3”OD P
ost and
1 7/8”OD.G
ate
F
rame
SB3015-
F
its
3”OD P
ost and
1 5/8”OD.G
ate
F
rame
made
in
the usa
:Flush Mount Gate Closer by Lockey
:Adjusting Screw Regulates Closing Speed
:Installs On Top,Middle Or Bottom Of Gate
:Mounts On Opening Side Of Gate And Pushes The Gate Closed
Specifications:
Max Gate Weight: 125 Lbs:
Max Gate Width: 54 In.
Max Opening Angle :90 Degrees
MODEL #
TB-175B
(BLACK FINISH)
MODEL #
TB-175W
(WHITE FINISH)
NOTES:ON SAMON2
The new generation of gate closers.Even easier to install and
smoother functioning.The final snap can easily be adjusted
after installation by turning the corresponding adjustment
screw.The Samson can be posed in almost every situation
thanks to the various brackets delivered with the products,
MODEL #
TB-100
(BLACK FINISH)
MODEL #
TIGER-9005(BLACK)
MODEL #
TIGER-ZILV(SILVER)
Compact hinge and gate closer in one *TIGER (Patented)
*Mammoth Self Closing Hinge Opens (180°) Includes Bottom Puma Hinge
*Closing speed and final snap can be adjusted after installation.Fast and easy
fixing with Quick-Fix.
*Maxium Weight 200 Lbs/Maxium Width 42”
• Automatic closure with adjustable closing force
• Aluminum powdercoated PUMA hinge included
• Powdercoated aluminum casing
• Fast and easy installation: Quick-fix• Esthetic design
• Vandalism proof• 180° opening
• For left and right turning gates
*Minium post size 2” & Minium Gate Size 1 1/2”
*Single Stainless Steel Bearing
*Pushers The Gate Close
• Tested at 500,000 movements
• Tested to -22° F
MODEL #
CM-2000
