STANDARD PUNCHED CHANNEL ON A SQUARE MADE IN THE U.S.A
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-12 1/2” 9/16" 2"
SBC-13 1/2” 9/16" 3”
SBC-14 1/2” 9/16" 4"
SBC-1412 1/2” 9/16" 4 1/2"
SBC-15 1/2” 9/16" 5"
SBC-16 1/2" 9/16" 6"
SBC-18 1/2" 9/16" 8"
1” STANDARD BAR
CHANNEL 1/8”THICK
WITH A 1/2” LIP
PUNCH ON A SQUARE
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-1142 1/2' 9/16" 2"
SBC-1143 1/2' 9/16" 3”
SBC-1144 1/2' 9/16" 4"
SBC-114412 1/2' 9/16" 4 1/2"
SBC-1145 1/2" 9/16" 5"
SBC-1146 1/2" 9/16" 6"
SBC-1148 1/2" 9/16" 8"
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-114258 5/8” 11/16” 2”
SBC-114358 5/8” 11/16” 3”
SBC-114458 5/8” 11/16” 4”
SBC-11441258 5/8” 11/16” 4 1/2”
SBC-114558 5/8” 11/16” 5”
SBC-114658 5/8” 11/16” 6”
SBC-114858 5/8” 11/16” 8”
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-1122 1/2” 9/16" 2"
SBC-1123 1/2” 9/16" 3”
SBC-1124 1/2” 9/16" 4"
SBC-112412 1/2” 9/16" 4 1/2"
SBC-1125 1/2" 9/16" 5"
SBC-1126 1/2" 9/16" 6"
SBC-1128 1/2" 9/16" 8"
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-112358 5/8” 11/16” 3”
SBC-112458 5/8” 11/16” 4”
SBC-11241258 5/8” 11/16” 4 1/2”
SBC-112558 5/8” 11/16” 5”
SBC-112658 5/8” 11/16” 6”
SBC-112858 5/8” 11/16” 8”
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-22 1/2' 9/16'" 2"
SBC-23 1/2' 9/16'" 3”
SBC-24 1/2' 9/16'" 4"
SBC-2412 1/2' 9/16'" 4 1/2"
SBC-25 1/2" 9/16" 5"
SBC-26 1/2" 9/16" 6"
SBC-28 1/2" 9/16" 8"
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-2358 5/8” 11/16” 3”
SBC-2458 5/8” 11/16” 4”
SBC-241258 5/8” 11/16” 4 1/2”
SBC-2558 5/8” 11/16” 5”
SBC-2658 5/8” 11/16” 6”
SBC-2858 5/8” 11/16” 8”
Model Sq. Sq. Holes
Number Picket Hole On
Size Size Center
SBC-2434 3/4” 13/16” 4”
SBC-241234 3/4” 13/16” 4 1/2”
SBC-2534 3/4” 13/16” 5”
SBC-2634 3/4” 13/16” 6”
SBC-2834 3./4” 13/16” 8”
1 1/4” STANDARD BAR
CHANNEL 1/8”THICK
WITH A 1/2” LIP
PUNCH ON A SQUARE
1 1/2” STANDARD BAR
CHANNEL 1/8”THICK
WITH A 1/2” LIP
PUNCH ON A SQUARE
2” STANDARD BAR
CHANNEL 1/8”THICK
WITH A 1” LIP
PUNCH ON A SQUARE
STEEL STAIR TREADS MADE
FROM 1/8" THICK NON-SKID FLOOR PLATE OR 16 GA. STEEL PLATE FOR CEMENT
READY TO WELD
WIDTH...........WALL .......MODEL........................ STYLE OF
........................ THICK...... NUMBER..................... STEP
36".................. .16 GA....... STEP-36SM.................. STAIR PANS
42" ................. .16 GA....... STEP-42SM.................. STAIR PANS
WIDTH WALL . MODEL .STYLE OF
THICK. NUMBER .STEP
36".................. .1/8"........... STEP-36FP.................... FLOOR PLATE
42".................. .1/8"........... STEP-42FP.................... FLOOR PLATE
44".................. .1/8"........... STEP-44FP.................... FLOOR PLATE
ARCHED GATE KITS
*For a 40" Wide Walk Gate
*3 Piece Set For a Walk Gate
Made From 1 1/2" x 1/2" x 1/8"
Standard Bar Channel
Pre-Punched On 5" Centers
On a Square
MODEL # ARCH12
STANDARD BAR CHANNEL PUNCH ON A SQUARE
1/8” Thick x 20 Feet
NOTE:THE FIRST HOLE WILL NOT BE ON THE CENTER
